Standard flexible fabric silo
Standard flexible fabric silos are the best solution for the indoor storage of bulk raw materials. They are certified for the storage of food products, chemical products, seeds, cereals, etc. These silos reduce infrastructure costs while ensuring optimal protection of stored products.
- Low investment cost
- Surface optimization
- Reduced maintenance thanks to the integrated filter
- Better traceability: FIFO / dedicated cell
Description
SYVRAC flexible silos are designed to meet the flexible storage needs of industries.
Air/product separation is achieved using the filtering fabric on the upper part of the silo, designed with a material that prevents your material from escaping and dusting your buildings. The fabric filters particles larger than 5 microns.
Product extraction is done with a vibrating base, which ensures total discharge.
The support structures are designed based on a standard model and adapted to each customer’s needs after a CAD study or a 3D scan of your buildings. This way, we best meet your requirements and installation constraints.
The Easyvrac device, a patent filed by Syvrac, allows for the replacement of flexible silo fabrics while reducing production shutdowns.
Key Features
- Storage Volume From 5 to 120m3
- Storage Capacity up to 45T of product
- Standard and Custom Design
- Easyvrac® Concept (Syvrac Patent)
Food Contact
SYVRAC flexible silos are designed to meet the strict requirements of the agri-food industry. Manufactured from certified food-contact materials, they guarantee optimal preservation of raw materials by preventing any contamination. Their hermetic design protects stored products from moisture, pests, and external contaminants. Furthermore,
Cleaning
- Dry Cleaning: Use of compressed air or specific brushes to remove dust and residues.
- Vacuum Cleaning: Use of an industrial vacuum cleaner to clean without the risk of releasing foreign bodies back into the silo. Vacuum cleaning of the fabrics does not require dismantling, which allows for minimal raw material supply immobilization.
- Dismantling Cleaning: The most complete and thorough cleaning for the food and pharmaceutical industries, ensuring the elimination of micro-organisms.
These methods ensure optimal hygiene, limiting the development of mold and guaranteeing compliance with health regulations. we collect your dismantled fabrics for treatment by our specialized service provider.
Installation
Flexible silos adapt to all types of industrial environments thanks to their modular and custom-made structure. Unlike rigid silos requiring foundations, flexible silos can be installed directly on existing platforms, which reduces infrastructure costs and allows for installation flexibility. Their customizable configuration makes it possible to maximize the use of available space, whether in buildings with limited height or on existing lines.
Our design office intervenes at the start of the project to design your future silo battery within your installation. We use FARO 3D scanning technology coupled with Solidworks to reproduce your installation to the nearest millimeter!
Assembly and Maintenance
The installation of fabric silos with the EASYVRAC patent is fast and does not require heavy equipment. Their patented EASYVRAC modular design allows for assembly in just a few hours, thereby minimizing production interruptions.
The unique patent divides the assembly time by 3 compared to standard market solutions.
In terms of maintenance, bulk fabric silos are easily accessible for inspection and replacement of elements. Fabric replacement is made fast thanks to the EASYVRAC system, which allows for disassembly in less than 2 hours. The fabric clipping system allows for the fabric to be disassembled without having to dismantle the support structure.
Stored Products
SYVRAC flexible silos allow for the storage of a large number of products used in the industrial sectors of food, feed, chemicals, plastics, compounding, seeds…
Your Bulk Products deserve Syvrac storage!
- Food Powders: flour, sugar, salt, powdered milk, spices;
- Granules and Cereals: rice, wheat, corn, coffee, seeds;
- Chemical and Mineral Products: fertilizers, metallic powders, pigments.
Thanks to their hermetic and modular design, these silos ensure optimal protection against humidity and oxidation, thus preserving the quality and traceability of stored products.
The design of SYVRAC flexible silos allows for the extraction of difficult products through the installation of a vibrating base and complementary extraction aids. The main advantage remains the “flexible” design, which allows for direct action on the stored product.
Options
All of our silos are standard; the options allow us to customize our silos according to your needs and requirements
EasyVrac
Vibrating bottom discharge
Weighing
Truck unloading
Level sensor
Our range of flexible silos
| Width | Length | Height | Volume | Weight in kg (d=0.55 g/liter) | Weight in kg (d=0.85 g/liter) |
|---|---|---|---|---|---|
| 1300 mm | 1300 mm | 2400 mm | 1,2 m3 | 700 kg | 1 000 kg |
| 1700 mm | 1700 mm | 3400 mm | 5 m3 | 2 750 kg | 4 250 kg |
| 2200 mm | 2200 mm | 3400 mm | 10 m3 | 5 500 kg | 8 500 kg |
| 2500 mm | 2500 mm | 4000 mm | 15 m3 | 8 250 kg | 12 750 kg |
| 2700 mm | 2700 mm | 4300 mm | 20 m3 | 11 000 kg | 17 000 kg |
| 3000 mm | 3000 mm | 4500 mm | 25 m3 | 13 750 kg | 21 250 kg |
| 3000 mm | 3000 mm | 5000 mm | 30 m3 | 16 500 kg | 25 500 kg |
| 3300 mm | 3300 mm | 5000 mm | 35 m3 | 19 250 kg | 29 750 kg |
| 3300 mm | 3000 mm | 5700 mm | 40 m3 | 22 000 kg | 34 000 kg |
| 3400 mm | 3400 mm | 6000 mm | 45 m3 | 24 750 kg | 38 250 kg |
| 3600 mm | 3600 mm | 6000 mm | 50 m3 | 27 500 kg | 42 500 kg |
| 3750 mm | 3750 mm | 6000 mm | 55 m3 | 30 250 kg | 46 750 kg |
| 4000 mm | 4000 mm | 6000 mm | 60 m3 | 33 000 kg | / |
