Stainless steel silo
Stainless steel silos enable outdoor storage of most industrial materials. Whether in powder, granule or bulk form, all products from the chemical, food and manufacturing industries can be stored in a stainless steel silo. Their stainless steel design ensures optimal hygiene, excellent corrosion resistance and long service life.
- Compliant with the most stringent food and chemical industry standards
- The most robust bulk storage silos available
- Numerous options available
Description
SYVRAC stainless steel silos are an ideal solution for the safe and hygienic storage of raw materials in powder or bulk form. They are suitable for the food, chemical, and water treatment industries. Made from 304 or 316 stainless steel, these silos ensure optimal resistance to corrosion and the most demanding industrial conditions. Their vertical cylindrical structure, combined with a conical bottom ranging from 15° to 60°, ensures smooth product flow and minimizes the risk of clogging. Their custom design, based on a standard foundation, allows perfect integration into industrial environments. Numerous options—integrated weighing, filtration systems, and explosion protection devices—make them adaptable to any client requirements. Standard finishes in cold-rolled steel with polished welds guarantee impeccable cleanliness in compliance with current food industry standards. Versatile and durable, SYVRAC silos optimize logistics while ensuring strict traceability of stored materials.
Main features
- Storage volume from 2 to 150 m³
- Construction in 304L or 316L stainless steel
- Fully customizable design
- Compliant with most industrial standards
Hygiene and Food Contact
SYVRAC stainless steel silos are designed to meet the strictest requirements for food storage. Compliant with FDA and EC 1935/2004 regulations, they ensure optimal sanitary safety for food products. Stainless steel, being an inert material, prevents any contamination of foodstuffs by avoiding the migration of undesirable substances. Its smooth, non-porous surface minimizes residue adhesion and limits bacterial growth, making cleaning and maintenance easier. Their robust design and high-quality finish ensure hygienic and durable storage, suitable for demanding industries.
Easy Cleaning
Cleaning stainless steel silos is simplified thanks to the nature of the material and solutions tailored to industrial requirements. Their smooth and resistant surface allows various cleaning methods — mechanical brushing, vacuuming, or deep cleaning using a hot water high-pressure washer, complemented by a dehumidifier to prevent microbial growth. These methods ensure optimal cleanliness without extended production downtime while complying with hygiene standards in the food and pharmaceutical industries.
Silo System Supervision
The industrial silo supervision system developed by SYVRAC enables real-time control of storage, transfer, and dosing operations for raw materials. It allows continuous monitoring of fill levels, environmental conditions (temperature, humidity), and equipment status. The integration of connected sensors and SCADA software facilitates centralized management, optimizing supply planning and reducing losses.
Batch tracking and traceability solutions make it possible to precisely identify the origin and destination of products, ensuring compliance with quality and regulatory standards (HACCP, ISO 22000, ATEX). Each batch can be tracked through unique identifiers associated with silo inputs and outputs, optimizing inventory management and enabling rapid response in the event of non-compliance.
In addition, the new-generation Human-Machine Interfaces (HMI) offer intuitive data visualization, making decision-making and predictive maintenance easier.
Safety and ATEX Compliance
SYVRAC stainless steel silos are designed to ensure maximum safety in explosive (ATEX) environments. The handling and storage of powders and granules present explosion risks, which is why our silos are equipped with prevention and protection devices such as explosion relief panels, flame arrestors, and explosion suppression systems. To limit the accumulation of electrostatic charges, they can be grounded and fitted with electrical continuity connections. In particular, internal conductivity bars prevent corona discharges, ensuring operation in full compliance with ATEX standards.
Discharge
SYVRAC offers several extraction technologies adapted to the different types of powders stored in its stainless steel silos. For compact powders or those sensitive to humidity, the use of air cannons helps to fluidize the material and improve its flow. Vibrating bottoms are an ideal solution to activate the flow of difficult products and prevent any build-up inside the silo. The vibro-fluidizer injects pressurized air to ensure continuous and smooth discharge. Finally, rotary valves or screw conveyors are used to guarantee precise dosing and optimal control of the discharge rate. These various solutions make it possible to adapt extraction to the specific characteristics of each stored product.
Options and Customization
At SYVRAC, we offer a wide range of options and customizations to adapt our stainless steel silos to the specific needs of each client. Options include various discharge valves (butterfly, slide gate, rotary valve), level sensors (capacitive, radar, ultrasonic), and integrated weighing systems for precise stock monitoring. We also provide specific treatments such as 304L or 316L stainless steel, electropolishing, and internal coatings for ultra-clean applications, as well as ATEX-certified versions for explosive environments. Our engineers support each project to ensure perfect integration with existing processes, guaranteeing safe, hygienic, and efficient storage.
Options
Each of our silos is standard; the available options allow us to customize them according to your needs and requirements.
Discharge via vibrating bottom
Thermal insulation
Truck unloading hose
Heater inside silo skirt
Silo skirt lighting
Jib crane with hoist
Lightning rod
Copper grounding 50 mm² ensuring a resistivity of 10 ohms.
Internal conductivity bar
Our range of stainless steel silos
| Silo Reference | Capacity (up to m³) | Capacity (up to T) | Diameter (mm) | Internal height (mm) | Total height (mm) | Inlet flange (mm) | Outlet flange (mm) |
|---|---|---|---|---|---|---|---|
| SILSS304-10 | 10 | 8.0 | 2200 | 4000 | 5500 | 200 | 150 |
| SILSS304-25 | 25 | 20 | 2800 | 6000 | 7500 | 250 | 200 |
| SILSS304-50 | 50 | 40 | 3600 | 8000 | 9500 | 300 | 250 |
| SILSS304-75 | 75 | 60 | 4000 | 10000 | 11500 | 300 | 250 |
| SILSS304-100 | 100 | 80 | 4400 | 12000 | 13500 | 350 | 300 |
| SILSS304-150 | 150 | 120 | 5000 | 15000 | 16500 | 400 | 350 |
This range is also available in 316 stainless steel and can be designed with brackets, legs, a skirt, or a platform. An ATEX or HAZLOC version is also available. Each part of the silo can be modified and customized according to your specific needs during the design and layout pre-study phase.
